P8400W Series Dehydrators



Up to 8400 SCFD

Standard Features:

  • Dual, Independently Functioning Systems
  • Real-Time Monitroing of Over 15 Points
  • Digital Display of All Operating Parameters
  • Remote Access and Alarm Reset Capabilities
  • Accurate Humidity Sensing within ±0.1% RH
  • Ultra Quiet Compressors
  • Removable Compressor Tray for Ease of Maintenance
  • 8,000 Hour Maintenance Interval

Accessories:

  • Installation Kit (P011752)
  • 6-Month Maintenance Kit (P011766)
  • 8,000 Hour Maintenance Kit (P011813)
  • Cycle Module Interface (PVDW31)
  • 1/2” Tubing (PPEC430 - sold per foot)
  • 3/4” Hose (P07490 - sold per foot)

General Specifications:

  P8402W
Output Capacity
(Both Systems / Single System)
Normal: 6,500 SCFD (184.1 SCMD) / 3,250 SCFD (92.1 SCMD) Continuous
Maximum: 8,400 SCFD (238 SCMD) / 4,200 SCFD (119 SCMD) Emergency
Power Requirements
(30 Amp Service Recommended)
220 - 230 VAC, 1-Phase, 50/60 Hz
Running Amps 15 Amps
Outlet Pressure Range 0 - 15 PSIG (0 - 103.4 KPa)
Outlet Air Relative Humidity Less than 2% RH - Less than -40°F/C Dew Point
Compressor Type Two-Cylinder, 3/4 HP, Oil-less Piston Type
Dehydrating Method Heatless Desiccant
Environmental Operating Temperature Range 40° to 85° F (5° to 30° C) Ambient
*Unit will go into SHUTDOWN Mode if Cabinet Temperature exceeds 120°F (49°C)
Noise Level 78.8 dBA at 3’ (1 m)
Heat Dissipation 6,000 BTU/hr
Alarms Standard Alarms - Complete readings of all critical measurement points, individual alarm indication display, including SNMP Communication
Outlet Connections 1/2” NPT Female
Dimensions 21” D x 25.25” W x 49” H (53.3 cm D x 64.1 cm W x 124.5 cm H)
Weight 265 lbs (120 kgs)


Need more information about Altec AIR's P8400W Series Dehydrators?


Please Contact Us.  We'd be happy to help.


Request a Quote
Download Specification Sheet
